Profec Water meter brass 2 1/2" male thread 16bar 0,1A 15m³/h DN50 24V blue CE/MID MD-A/MD-AP type TL multi jet horizontal with pulse option

Product number: 0892311

Manuals & drawings

Select your item below or order directly via full product table
Size
Q3 ISO 4064 (2005)
All prices shown are gross prices. Please log in or contact sales for custom, discounted pricing.
Price excl. VAT £68.75 / 1 pcs
£68.75 / pcs
Price incl. VAT £82.50 / 1 pcs
£82.50 / pcs
Out of stock, not expected before 2026-02-08
Item 0892311 is out of stock and not expected before: 2026-02-08
pcs
Box qty:
1 pcs
MSQ:
1 pcs

Fast, free shipping on orders over £350*

Your trade partner in water technology

8.9/10 Read reviews

Frequently bought together

Profec Gate valve brass 2 1/2" female thread 16bar DN65 type 201
0400106
Profec Gate valve brass 2 1/2" female thread 16bar DN65 type 201

£63.25*
Profec Ball valve brass nickel plated 2 1/2" female thread 25bar type 100
0403008
Profec Ball valve brass nickel plated 2 1/2" female thread 25bar type 100

£97.71*
Profec Cap PVC-U 2 1/2" female thread 10bar grey type plain
7036405
Profec Cap PVC-U 2 1/2" female thread 10bar grey type plain

£4.46*
Profec Ball valve brass nickel plated 2 1/2" female thread x male thread 25bar type 104
0403023
Profec Ball valve brass nickel plated 2 1/2" female thread x male thread 25bar type 104

£98.88*
Profec Nr. 23 Pipe nipple stainless steel 316 2 1/2" male thread 16bar 100 mm
0080409
Profec Nr. 23 Pipe nipple stainless steel 316 2 1/2" male thread 16bar 100 mm

£16.70*
Profec Elbow 90° PVC-U 2 1/2" female thread 10bar grey
0110156
Profec Elbow 90° PVC-U 2 1/2" female thread 10bar grey

£15.60*
Profec Socket PVC-U 2 1/2" female thread 10bar grey
7027463
Profec Socket PVC-U 2 1/2" female thread 10bar grey

£9.80*
Profec Nr. 130 T-piece 90° cast iron galvanised 2 1/2" female thread 25bar DVGW
1013010
Profec Nr. 130 T-piece 90° cast iron galvanised 2 1/2" female thread 25bar DVGW

£26.93*
Profec Nr. 23 Pipe nipple steel galvanised 2 1/2" male thread 16bar 180 mm
1068180
Profec Nr. 23 Pipe nipple steel galvanised 2 1/2" male thread 16bar 180 mm

£16.61*
Rubber seal SBR 2 1/2" black
0110877
Rubber seal SBR 2 1/2" black

£1.57*

Technical details

  • Length
    280/300 mm
  • Material
    brass
  • Connection
    male thread
  • Voltage
    24V
  • Model
    MD-A/MD-AP
  • Diam.
    2 "
  • Pulse option
    100 ltr
  • Type
    TL multi jet
  • Type
    horizontal with pulse option
  • Approval
    CE/MID
  • Width
    125 mm
  • Capacity Qmax
    30 m³/h
  • Pressure
    16 bar
  • DN
    50
  • Capacity Qn
    15 m³/h
  • Colour
    blue
  • Max. temp.
    50 °C
  • DN
    2 "
  • EAN
    4019305190183
  • Part number
    0892311
  • Manufacturer
    Profec

Dimensions

  • H
    172 mm

Variants

Product number:
Size
Q3 ISO 4064 (2005)
Price
Box qty
MSQ
Stock
0892315
3/4"
2.5 m³/h
£68.75
10
1
0892316
1"
4 m³/h
£68.75
10
1
0892317
1 1/4"
6.3 m³/h
£68.75
5
1
(57)
0892309
1 1/2"
10 m³/h
£68.75
5
1
0892310
2"
16 m³/h
£68.75
2
1
(79)
0892311
2 1/2"
25 m³/h
£68.75
1
1
