Rovatti Multi-stage centrifugal pump stainless steel 2" female thread 400VAC black type compact ME 5KV50C-18/8
Product number: 7024343
Manuals & drawings
Select your item below or order directly via
full product table
All prices shown are gross prices. Please log in or contact sales for custom, discounted pricing.
Price excl. VAT
£1,888.70 / 1 pcs
£1,888.70 / pcs
Price incl. VAT
£2,266.44 / 1 pcs
£2,266.44 / pcs
Available at supplier, please contact us
- available on request, please contact sales team
Frequently bought together
0412050
0075085
0080936
Technical details
-
Max flow rate24 m³/h
-
Press2 "
-
Power4 kW
-
Pump bodystainless steel
-
IP valueIP55
-
Shaftstainless steel
-
Materialstainless steel
-
Suction2 "
-
Colourblack
-
Impellers8
-
Connectionfemale thread
-
Output Power5,5 HP
-
Frequency50 Hz
-
Material impeller 1noryl
-
MWC88
-
Size2"
-
EAN4019305682282
-
Part number7024343
-
ManufacturerRovatti
Dimensions
-
G-1180 mm
-
Cb-2409 mm
-
Cr-1139 mm
-
O14 mm
-
ØDi-250 mm
-
ØDi-22 "
-
L819 mm
-
Cl-1139 mm
-
G-2180 mm
-
ØDi-12 "
-
Cb-140 mm
-
Lb564 mm
-
ØDi-150 mm
Similar products
Product description
The inlet is not at the same level as the outlet because of the single wall within the body of the pump which makes this pump more competitively priced when compared to double walled pumps.
The Compact ME type is the most space efficient pump (21cm x 21cm cast iron black pump base), it is ideal for installations with restricted space.
The simple construction of the Compact ME type makes it easy to disassemble the motor unit in order to change the seal and the impellers.
For installations where the inlet and outlet need to be at the same level please consult with us regarding the MEKV50T model. This can be required, for example, when the suction pipe and pressure pipe are at the same level.
Every pump is delivered with 2'' I.D. (inside diameter) counter flanges.
The Compact ME type is able to supply a wide range of pressures which allows it to be used for diverse installations of medium and high pressure in irrigation with lower capacities than the Europa types.
The Compact ME type is the most space efficient pump (21cm x 21cm cast iron black pump base), it is ideal for installations with restricted space.
The simple construction of the Compact ME type makes it easy to disassemble the motor unit in order to change the seal and the impellers.
For installations where the inlet and outlet need to be at the same level please consult with us regarding the MEKV50T model. This can be required, for example, when the suction pipe and pressure pipe are at the same level.
Every pump is delivered with 2'' I.D. (inside diameter) counter flanges.
The Compact ME type is able to supply a wide range of pressures which allows it to be used for diverse installations of medium and high pressure in irrigation with lower capacities than the Europa types.
